參數配置

 功能特點

4路無級調光，可控LED燈;

4路強電或弱電開關量控制；

模擬量控制（256級調光）;

具有手動和中控同時調光功能;

面板上具有液晶顯示屏，可實時顯示燈光亮度狀態;

具有預設燈光亮度的功能;

輸出電壓部分具有短路保護功能;

可編程定義各種邏輯開關動作(互鎖、時序開關、同步動作等)；

具有手動和中控或電腦軟件同時管理功能；

斷電最后一次狀態保存功能；

每路額定功率2KW；

標準RS-232/RS-485控制協議；

輸入電壓≤280V；

平放或墻上固定安裝方式；

設備采用內置RS485方式，通過切換ID地址識別不同設備、設備間可以級連到16臺；

本產品應用于燈光開關、窗簾開關、屏幕升降、會標升降、投影機電動吊架升降及其他開關量遠程控制場合。

Functions and features

4 way stepless incandescent lamp light modulation;

Analog control (256 levels light modulation);

With hand and central controller simultaneous light modulation function;

There is a LCD display on the panel, which can show the brightness of the lamps in real time;    With lamp brightness presetting function;

Last state before electricity breaking storage function

There is a short circuit protection function for the output voltage;

The equipment adopts built-in RS485 method to recognize different equipments through switching the ID address, and the amount of equipments in cascade connection can be up to 16;

Applicable scope: central control systems or software control systems such as SVS, SV-PROII, SV-PRO, SV-9000, SV-8000, SV-6000, CRSTRON and AMX.

This production is applicable to high-class meeting rooms, multifunctional halls, training centers and audio-visual education classrooms, etc;
